Description

Machine Specifications:

• Capacity Round 12″ dia.
• Rectangular 12″ x 12″
• Blade:
  • Length 13′ 6″
  • Width 1″
  • Thickness .035″
• Blade: Speed 75-400 SFM (with VFD option, 50-350)
• Blade: Tension manual (26,000 psi)
• Blade: Guides carbides (coolant lubricated)
• Blade: Wheel Diameter 16″ diameter
• Motors: blade drive 3hp, 5HP optional
  • Hydraulic 2hp
  • Pumps: Hydraulic pump 6 1/2 gpm
• Coolant Pump 3 1/2 gpm
• Hydraulic Tank 7.5 US gallons
• Coolant Tank 23 US gallons
• Hydraulic System Pressure 500 psi
• Vise Control hydraulic
• Shuttle Stroke 0-22″ single stroke multi shuttle capability
• Table Height 31″
• Control Panel waist height
• Machine Weight 3800 lbs.
• Maximum Workload 6000 lbs.
• Overall Dimensions 88″ W x 78″ L x 68″ H
