Description

SPECIFICATIONS

SQUARE: 10″ X 10″
ROUND: 10″
LENGTH CONTROL: PROGRAMMABLE UP TO 99 JOBS
BLADE DIMENSIONS: 11’10” X 1″ W X .035″ THICK
BLADE TENSION: 25,000 – 30,000 PSI
BLADE SPEED (VFD): 50 – 350 SFM
BLADE GUIDES: ROLLER AND CARBIDE
BLADE WHEEL DIAMETER: 16″
BLADE DRIVE MOTOR: 5 HP
HYDRAULIC PUMP DRIVE MOTOR: 1 HP
HYDRAULIC PUMP: 6-1/2 GPM
COOLANT PUMP: 3-1/2 GPM
HYDRAULIC TANK: 4 GALLONS
COOLANT TANK: 6.6 GALLONS
HYDRAULIC PRESSURE SYSTEM: 600 PSI
SHUTTLE STROKE (SINGLE STROKE): 0 – 24″
TABLE HEIGHT: 31″

GENERAL

DIMENSIONS: 80″ W X 56″ L X 60″ H
MACHINE WEIGHT: 2,500 LBS
ELECTRICS: 240 VOLTS, 3 PH, 60 CYC
