Description

Automatic, horizontal pivot band saw designed to give you the best cost per cut on the market.
The S-20A, automatic scissor style band saw features a swing head design and provides exceptional miter cutting capability for light to medium duty applications.
Featuring a 13″H x 18″W capacity at 90°, 3 HP motor, and 1″ blade, the S-20A is a versatile, automatic scissor style band saw ideal for use in tight working spaces.

Capacity Rectangular (h x w) Round
90° 13″ x 18″ 13″
45° 13″ x 10 3/4″ 12″
30° 13″ x 7 3/4″ 8 1/2″
Blade Size – 1” x 14’ 10”
Blade Drive – 5 HP VFD
Machine Voltage – 480 v (all other voltages require optional transformer)
Blade Speed – 75-330 SFM
Coolant Tank Capacity – 12 Gallons
Work Load – 5,000 lbs.
Machine Weight – 3,800 lbs.
Table Height – 31”
Dimensions (w x l x h) – 93” x 86” x 52”

Automatic Control – Automatic mode provides for powered saw functions along with automatic clamping and indexing of material. Program the number of pieces needed and the saw will automatically index and cut required pieces.
Movable Saw Guide Arm – Riding on linear bearings, the left movable saw guide arm can easily be positioned and locked into place when adjusting to the workpiece.
Cast Iron Saw Head – Heavy, cast iron head helps absorb vibrations when cutting structural material helping reduce cutting noise, increasing band life and providing better quality cuts.
Pivoting Saw Head – The saw head can be swung a full 60 degrees simplifying the process of cutting angles when needed.
